Nominal Voltage....................................................12 volts (6 cells)

20-hr. (600mA to 10.50 volts) ........................................ 12.0 AH

10-hr. (1.1A to 10.50 volts) ............................................ 11.0 AH

5-hr. (2.1A to 10.20 volts) ............................................. 10.5 AH

1-hr. (7.25A to 9.00 volts) ............................................. 7.25 AH

15-min. (21.5A to 9.00 volts) ..........................................5.38 AH

Approximate Weight ......................................... 7.92 lbs. (3.59 kg)

Energy Density (20-hr. rate) ............. 1.69 W-h/in3 (103.41 W-h/l)

Specific Energy (20-hr. rate) ............ 18.18 W-h/lb (40.08 W-h/kg)

Internal Resistance (approx.) ..................................... 20 milliohms

Max Discharge Current (7 Min.) ............................... 36.0 amperes

Max Short-Duration Discharge Current (10 Sec.) .. 120.0 amperes

Shelf Life (% of nominal capacity at 68°F (20°C)

1 Month ................................................................................. 97%

3 Months ................................................................................ 91%

6 Months ............................................................................... 83%

Charge ...............................................-4°F (-20°C) to 122°F (50°C)

Discharge .........................................-40°F (-40°C) to 140°F (60°C)

Case ..................................................................................ABS Plastic
